Product Description
RK Industrial Components leading manufacturer of Brass knurling inserts for plastic Industries, Communication equipments, Automotive Industries, Electrical & Wiring Device Cases etc. We offer a full line of Inserts for all methods of installation, including ultrasonic, heat, thermal, press-in and mold-in. Although we produce various brass knurling inserts as per custom design & specification, we have standard series of Threaded Inserts such as Straight Hole, Blind (Closed bottom), Collar Inserts, Ultrasonic, Press in, Tri Slotted Inserts etc. |
|||
| Products Range of Brass Knurling Inserts: | |||
|
|||
| Applications of Brass Knurling Inserts: | Instrumentation, Telecommunications, Other Plastic Cases Assembly | ||
| Special Features of Brass Knurling Inserts: » In such cases the length of insert is very important for proper closing of moulding die. We maintain length of such inserts within tolerance of -0.05mm. » Thread Size Starts from M2 to M50, BA, BSW, BSPT, and BSF & American Threads like UNC, UNF, UNEF, and NPT are also available as per custom requirements. » Straight, Diamond, opposite diagonal etc. are the knurling options available to give solid gripping to Molding applications. » Inserts with collar series provides Options to use Flange to make Electric Contact » Opposing Diagonal Knurls provide excellent Torque Resistance. » Vertical Undercuts in Tri Series Provides superior Tensile Strength » Blind thread or closed bottom Inserts prevents plastic from entering the bottom of the insert. |
|||
Installation of Brass Knurling Inserts: |
Threaded In Installation, Ultrasonic Installation, Thermal/Heat Installation, Mold-In InstallationPress-In Installation | ||
Knurling Available of Brass Knurling Inserts: |
Straight, Diamond, Unidirectional, Both blind and through inserts are available with no minimum Quantity | ||
| Material Grades for Brass Knurling Inserts: | High Grade Free Cutting Brass, IS 319 Brass Free Cutting, Free Cutting Brass as per BS 249 type (i), Any special brass material compositions as per customer’s requirement | ||
| Threads for Brass Knurling Inserts: | ISO metric, MM, PG, BSW, BSP, BSB, BSF, BA, NPT, NPTF, UNC, UNF, UNEF etc, Any threads as per customer's design | ||
Length / Size of Brass Knurling Inserts: |
Begins from M2 or equivalent threads and up to any size as per custom design or requirement | ||
| Finish and Coating of Brass Knurling Inserts: | Brass Natural, Electro Tinned, Nickel, Chrome, Led, Silver, Gold, Zinc Blue or any special finish/plating as per customer specifications. | ||
| Quality of Brass Knurling Inserts: | Incoming Inspection, In-process Inspection and 100% inspection before shipment Pre-shipment sample on clients demand, HD pictures of the production process on clients demand |
||
| Packing Details of Brass Knurling Inserts: | One Piece Packing, Inner Box, Customized Packing, Poly Bag, Outer Cartons, Standard Export Packaging, Plastic Bag, the reels are packed in wooden crate/box, Relevant markings are provided in each outer package and as per client specifications. | ||
| Lead Times for Brass Knurling Inserts: | Prompt or We will give you lead time based on your project | ||
| Available Price for Brass Knurling Inserts: | EX-Work, FOB — Freight On Board, DDP, C&F — Cost and Freight, CIF — Cost, Insurance & Freight and etc. | ||
| Port of Discharge for Brass Knurling Inserts: | Nhava Sheva Port - Mumbai, ICD Khodiyar- Ahmedabad, Mundra port, Air Cargo Complex - Ahmedabad, BOM Air Cargo Complex - Mumbai etc. | ||
| Payment Term for Brass Knurling Inserts: | 30% advance and rest of against T/T at sight against copy of B/L. | ||
| Availability of Brass Knurling Inserts: | In India as well as In Many Foreign Countries | ||
| Manufacturing Unit of Brass Knurling Inserts: | Jamnagar, Gujarat, India | ||
| Market for Brass Knurling Inserts: | India, United State, United Arab Emirates, Germany, Saudi Arabia, United Kingdom, Kenya, Kuwait, Singapore, Oman, Qatar, Australia, Thailand, Switzerland, Mexico, Russia, Turkey, Spain, Malaysia, Indonesia, Greece, Africa, Egypt, Sweden, Japan, China, Portugal, Hungary, Algeria, Czech Republic, France and many more countries. | ||
| Any Type of Brass Knurling Inserts can be developed and supplied exactly as per customer specifications | |||
